Descripton:
LSQ-S1-SS CLOSE TYPE HYDRAULIC QUICK COUPLING (stainless steel 316)Applications: The LSQ-S1-SS Series brings to the industry a proven design for use on construction equipment, forestry equipment, agricultural machinery, oil tools, Oil equipment steel mill machinery, and other demanding hydraulic applications.

LSQ-S1-SS Series couplings feature:
1.Poppet valves available to prevent uncoupled leakage.
2.Poppet valves open automatically when coupled, within rated working pressure, to keep the flow expeditely.
3.Dependable ball-locking mechanism holds the mating halves together.
4.Socket and plug are precision machined from solid bar stock.
5.LSQ-S1-SS series conforms to the standard of ISO 7241-A.
6.Compatible with PARKER 6600 Series, FASTER ANV Series, AEROQUIP 5600 Series and HANSEN HA 15000 Series.
